Plug Building - Got Wood? Got Plug?

Reply

Thread Tools Rate Thread Display Modes
Old 01-04-2002, 06:02 PM   #1
TheSpecialist
Hardcore Equipment Tester
iTrader: (0)

TheSpecialist's Avatar

Join Date: Mar 2001
Location: Abington, MA
Posts: 6,234
Blog Entries: 1
Got mackeral?

How is this paint job. I don't own an airbrush.
Attached Thumbnails
Click image for larger version

Name:	block island bass.jpg
Views:	426
Size:	61.6 KB
ID:	485

Bent Rods and Screaming Reels!

Spot NAZI
TheSpecialist is offline   Reply With Quote
Old 01-04-2002, 07:24 PM   #2
Plum Ireland Stripers
Registered User
iTrader: (0)

Plum Ireland Stripers's Avatar

Join Date: Nov 2001
Location: Haverhill, MA
Posts: 9
Thumbs up

Specialist that is one great looking plug, I will be happy to reach your level of plug building
John H
Plum Ireland Stripers is offline   Reply With Quote
Old 01-04-2002, 07:45 PM   #3
JohnR
Certifiable Intertidal Anguiologist
iTrader: (1)

JohnR's Avatar

Join Date: Feb 2000
Location: Somewhere between OOB & west of Watch Hill
Posts: 35,270
Blog Entries: 1
It looks like it's fresh out of a Gibbs package - it's even missing the hooks - ( just kidding guys - just passing some winter doldrums here... no nastygrams please)

Seriously - that's pretty nice, how and where did you add the weights...

~Fix the Bait~ ~Pogies Forever~

Striped Bass Fishing - All Stripers


Kobayashi Maru Election - there is no way to win.


Apocalypse is Coming:
JohnR is offline   Reply With Quote
Old 01-04-2002, 08:34 PM   #4
mrpogie
Registered User

Join Date: Oct 2001
Posts: 129
Man, you're like a runaway train. Tell me, do you come home from work and throw your coat on a chair and race down the cellar stairs like a mad scientist? lol Very nice work. Are those markings done with permanent marker? I found something out when I was doing the plugs for the swap. I signed my name on the bottom before I envirotexed the plug. After a few minutes the signature began to move around and flow with the envirotex. It didn't ruin it but distorted it quite a bit. It looked pretty cool almost gothic style printing and something I could never get to come out like that again. I guess the point I'm making is envirotex may make your markings run together or melt a little bit. Maybe you should try a little paint and markings on a test dowel and envirotex it to see if it runs before you do that plug and possibly get undesirable results. If it does run the markings a simple way to cure this is to spray one coat of clear lacquer or enamel over the plug to seal the markings underneath. Then proceed with the envirotex. Make sure you stay with the same type paint you painted the plug with. If you used lacquer color use lacquer clear, etc. good luck, don't hesitate to ask questions. ...mrpogie
mrpogie is offline   Reply With Quote
Old 01-05-2002, 12:00 AM   #5
TheSpecialist
Hardcore Equipment Tester
iTrader: (0)

TheSpecialist's Avatar

Join Date: Mar 2001
Location: Abington, MA
Posts: 6,234
Blog Entries: 1
Mr. Pogie you been spying on me? Yup I come home from work and rush to the basement. I did use a sharpie for the lines. I may not envirotex this one. I might test it first and see how she swims. I put the weight behind the mid hook and in a line down to the rear hook. I wonder if I could use Testa model paint and just paint the stripe by hand, or use the paint from the spray can and hand brush them. I wish I had a scale so I knew how much this thing weighs. For the weights I improvised, I had no buck shot on hand. I cut some .38 wadcutters into lengths to fit the cavities. It is about a1/2" shorter than the original and seems a little lighter. I will have to compare it when I add the hardware. I might just pick up a clear coat tomorrow, so I can envirotex it.

John H I have seen your plugs and they blow mine away. Thanks for the compliment though. I appreciate it.

Last edited by TheSpecialist; 01-05-2002 at 12:04 AM..

Bent Rods and Screaming Reels!

Spot NAZI
TheSpecialist is offline   Reply With Quote
Old 01-05-2002, 08:01 AM   #6
Bob Senior
Registered User
iTrader: (0)

Bob Senior's Avatar

Join Date: Apr 2001
Location: Wakefield, RI
Posts: 298
Specialist:

What name/number and brand is the green paint you used? If you can see it in the attached picture, the green on the little neck popper is too dark but I haven't found a lighter green in the right shade.

Yours looks like the perfect green.
Bob Senior is offline   Reply With Quote
Old 01-05-2002, 08:50 AM   #7
TheSpecialist
Hardcore Equipment Tester
iTrader: (0)

TheSpecialist's Avatar

Join Date: Mar 2001
Location: Abington, MA
Posts: 6,234
Blog Entries: 1
Bob it's Painters touch by Rustoleum. It is the only color I boughtwithout a sticker saying thecolor code number. I got it at Home Depot. I think it was the only green in this brand. Hope it helps.

Bent Rods and Screaming Reels!

Spot NAZI
TheSpecialist is offline   Reply With Quote
Old 01-05-2002, 08:52 AM   #8
Bob Senior
Registered User
iTrader: (0)

Bob Senior's Avatar

Join Date: Apr 2001
Location: Wakefield, RI
Posts: 298
Thanks. I'll get some and try it.
Bob Senior is offline   Reply With Quote
Old 01-06-2002, 10:25 PM   #9
TheSpecialist
Hardcore Equipment Tester
iTrader: (0)

TheSpecialist's Avatar

Join Date: Mar 2001
Location: Abington, MA
Posts: 6,234
Blog Entries: 1
Mr Pogie put clear laquer 2 coats, then I envirotexed. No runs it works, you are a genious. From now on I will paint details like that with a brush and paint.

Bent Rods and Screaming Reels!

Spot NAZI
TheSpecialist is offline   Reply With Quote
Old 01-07-2002, 06:11 AM   #10
mrpogie
Registered User

Join Date: Oct 2001
Posts: 129
Specialist, there are some fine details that would be hard to do with paint and a brush. Markers are OK to use as long as you clear over them. One thing I failed to mention was after I put clear over the graphics on the plug I let it dry good and scuff the plug down with a scuff pad. I use 3M gray scuff pads and I don't go crazy but just take the shine off the plug. I feel it gives the envirotex something to bite into. I have a bunch of plugs that were done without scuffing and they holdup fine. It's just something I started doing while trying to refine my system for best possible results. The more options you have the better off you're going to be. ...mrpogie
mrpogie is offline   Reply With Quote
Old 01-08-2002, 12:09 AM   #11
bloocrab
Callinectes sapidus
iTrader: (0)

bloocrab's Avatar

Join Date: Oct 2001
Posts: 6,277
Bill, I'm not picking on ya......but what kind of camera did you take that mackerel picture with....was a digital?...just curious...or did you scan something.....I'm still shopping....and I want to make the right purchase ....I'm not trying to be a hammerhead!! I know you own guns!!!
Attached Thumbnails
Click image for larger version

Name:	14#holyoke.jpg
Views:	441
Size:	121.5 KB
ID:	500
bloocrab is offline   Reply With Quote
Old 01-08-2002, 06:04 PM   #12
TheSpecialist
Hardcore Equipment Tester
iTrader: (0)

TheSpecialist's Avatar

Join Date: Mar 2001
Location: Abington, MA
Posts: 6,234
Blog Entries: 1
Bloo it was a Sony digital. I bought it for my wife for xmas, and we are still learning how to use it. I think I had the settings wrong. It really is a nice little camera, it can make mini movies and stuff. I just have had no time to play with it since I started my new addiction.

Bent Rods and Screaming Reels!

Spot NAZI
TheSpecialist is offline   Reply With Quote
Old 01-08-2002, 06:22 PM   #13
GBOUTDOORS
Registered User
iTrader: (0)

GBOUTDOORS's Avatar

Join Date: Jan 2002
Location: OUTDOORS/ Fairhaven,Ma.
Posts: 1,989
Send a message via AIM to GBOUTDOORS
Hey Specialist are you going to the East Bay show if so I have a brand new air brush and gear you can have and I would like to see someone get some use out of it. If not could get it to you some other way?
GBOUTDOORS is offline   Reply With Quote
Old 01-08-2002, 10:20 PM   #14
TheSpecialist
Hardcore Equipment Tester
iTrader: (0)

TheSpecialist's Avatar

Join Date: Mar 2001
Location: Abington, MA
Posts: 6,234
Blog Entries: 1
GB unfortunately I won't be making the show. I was just talking to my wife yesterday about the need for an airbrush. I have been painting in the basement, windows open, and the fumes are still wafting upstairs. I sure would love the airbrush, once I get a little better at this plug thing I could hook you up. I will pm you my phone number and maybe we can get together thanks. Here are three of my first, I had help on two of the paint jobs.
Attached Thumbnails
Click image for larger version

Name:	picture026_19may04.jpg
Views:	384
Size:	18.2 KB
ID:	502

Bent Rods and Screaming Reels!

Spot NAZI
TheSpecialist is offline   Reply With Quote
Old 01-08-2002, 10:30 PM   #15
GBOUTDOORS
Registered User
iTrader: (0)

GBOUTDOORS's Avatar

Join Date: Jan 2002
Location: OUTDOORS/ Fairhaven,Ma.
Posts: 1,989
Send a message via AIM to GBOUTDOORS
To bad can't get to the show. Plugs look great for your first ones now will they catch?? I took a walk down to my shop to look for airbrush and pulled it out still just as new as when I got it. We will have to hook up some how to get it to you. I had a great little paint box that I built but it whent out with the trash one day that I was cleaning up but I'm sure you could build one it helps to keep the over spray down.
GBOUTDOORS is offline   Reply With Quote
Old 01-08-2002, 10:45 PM   #16
TheSpecialist
Hardcore Equipment Tester
iTrader: (0)

TheSpecialist's Avatar

Join Date: Mar 2001
Location: Abington, MA
Posts: 6,234
Blog Entries: 1
I pm'd you my number give me a call Saturday around 10am if you have time, and we will see if we can make some arrangments.

Bent Rods and Screaming Reels!

Spot NAZI
TheSpecialist is offline   Reply With Quote
